Plastic Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C

Plastic Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C
Plastic Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C Plastic Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C Plastic Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C

Large Image :  Plastic Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C

Product Details:
Place of Origin: Ningbo, China
Brand Name: ElectroAMR TM
Certification: MC, OIMLR 49,ISO 4064-1:2005
Model Number: LX-20DWY1
Detailed Product Description
High Light:

plastic multi jet water meter

,

read residential water meter

 Plastic  Electronic Home / Residential Water Meter AMR , IP68 ,RF 470 ~ 510MHz , Class C

Quick Detail:
Feature:high accuracy ,high  precision, potable
Meter body material :FDA engineering Nylon plastic, full plastic
two automatic meter reading solutions:
-Hand PDA reader, walk-by or drive-by
-Ad-hoc network

Technology:flow rate sensor technology
Accuracy:Class C
AMR electronic water meter is one originally real electronic water meter, not the conventional mechanical-electronic water meter, developed by flow rate sensor technology, high accuracy & Class C. AMR by RF module.


Description:

AMR electronic water meter is developed by contactless electronic flow rate sensor technology. It is one real electronic water meter and AMR water meter.
AMR electronic water meter is compatible with two automatic meter reading solutions:
-Hand PDA reader, walk-by or drive-by
-Ad-hoc network


Applications:
Residential water meter, home water meter,domestic water meter

Specifications:
1. Water Meter Specifications:


FEATURE

SPECIFICATION

LX-20DWY1

Flow range

0.025m3/h~4.0m3/h

Permanent flow rate Q3

4.0m3/h

Start flow

5l/h

Flow turndown Q3/Q1

125,160

Maximum tolerance

Q2≤Q≤Q4 : ±2%   Q1≤Q≤Q2: ±5%

Accuracy

Class C

Temperature

T30

Enclosure rating

IP68

Pressure grade

MAP10

Pressure loss

△p63

Installation

H

Battery life

8 years

LCD digital showing

9 digit LCD, 0.00001 m3~9999.99999 m3

Meter body materials

FDA engineering Nylon plastic, full plastic

Radio Frequency

430~440MHz, 470~510MHz, 868~870MHz, 902~928MHz



Competitive Advantage:


  • Provides accurate flow rate measurement by the no-contact flow rate sensor, Class C
  • Unaffected by grit or particulates
  • 15 years life Outlasts all conventional mechanical water meters’ 6 years life
  • Much cost saving compared with No Moving Parts AMR water meters such as electromagnetic or ultrasonic water meters
