Ultrasonic Thickness Meter TM-8812

Large Image : Ultrasonic Thickness Meter TM-8812

Product Details:

Place of Origin:	China
Brand Name:	OMNI
Model Number:	OMNI
Category:	Battery Testers

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Packaging Details:	1 unit in a case
Delivery Time:	7 working days
Payment Terms:	L/C,T/T,Paypal
Supply Ability:	1000 unit per month

Contact Now

Detailed Product Description

High Light:

Ultrasonic power measuring meter

ultrasonics distance measurement

Products

TM-8812

Measuring range (metric/imperial): 1.2-225mm,0.05-9inch

Operating principle: ULTROSONIC

Materials measured: any hard materials, including steel, cast iron, aluminum, red copper, brass, zinc, quartz glass, polyethylene, PVC, gray cast iron, nodular cast iron and other materials

Sound velocity: 500-9000m/s

Lower limit steel pipes: Ñ15x2.0mm, Ñ20x3.0mm determined by the transducer

Calibration block: included

Resolution: 0.1mm

Accuracy: ±(0.5%n+0.1)

RS232C interface: with RS232C

Power supply: 4x1.5V AAA (UM-4)battery

Battery indicator: low battery indicator

Operating conditions:0-+45â(32â-104â),≤90%RH

Dimensions: 120x62x30mm

weight: 164g(not including battery)
