ASME / ANSI Stainless Steel Heat Exchanger Tube with polishing / acid pickling

Large Image : ASME / ANSI Stainless Steel Heat Exchanger Tube with polishing / acid pickling

Product Details:

Place of Origin:	China
Brand Name:	anpu
Certification:	PED
Specification:	323.9

Payment & Shipping Terms:

Minimum Order Quantity:	5 Tons
Packaging Details:	Bundle Package
Delivery Time:	30 days
Payment Terms:	T/T or L/C
Supply Ability:	5,000 tons per month

Contact Now

Detailed Product Description

High Light:

stainless steel heat exchanger tubing

Heat exchanger stainless steel tube

ASME / ANSI Stainless Steel Heat Exchanger Tubes with polishing / acid pickling

Specifications:

1) Diameters: 4 - 76.2mm
2) W.T.: 0.4 - 2.5mm
3) Grades: 316L/304/304L/310S/317L/2205/321,etc.

4) standard:GB/ISO/EN/ASTM/JIS,etc.

5) application range:widely use in the foodstuff,medical equipment,power,boiler,cooler,auto,condenser etc.

6) packing: inner packing:1 pc/plastic bag;outer packing:bundles in weaving bags or in plywooden case.

standard specifications	ASME/ANSI, JIS, DIN, EN,GOST	Product Range	Stainless steel seamless pipes and tubes
Export Percentage	60%	Export Markets	Middle east, south and east Asia, Russia, South America
Sales Volume	300,000,000 (300million)	Primary Competitive Advantages	High quality, Favourite price; Prompt Delivery
No. of Production Lines	18	Investment on Manufacturing Equipment	20,000,000(20million)
NO.of R&D Staff	6	NO.of Total Staff	300
Annual production capacity	11000TONS	No. of Engineers	20
Year Established	1992	Monthly Capacity	1200 tons
Raw material	Tsingshan,Baosteel,Jiuli,Yongxing	Factory Size in Square Meters	33333 SQ.M
Certificates	ISO9001:2000; DNV,GOST	Current Principal Customers:	sinopec, CNPC, nuclear plant
Type of Machinery	cold drawn machine, cold rolling equipment, broaching machine, automatic solution annealing furnaces, straighteners, test equipment	Capital	ZHEJIANG PENGYE STAINLESS STEEL TUBE INDUSTRIAL CO.,LTD: 100,800,000RMB LISHUI NEW PENGYE SPECIAL STEEL CO.,LTD:10,420,000 RMB

Size:

Outer diameter: 6 to 830mm
Wall thickness: 1 to 60mm
Length: maximum 16,000mm or customized
Customized sizes are accepted

Standards:

GB/T 14975-2002, GB/T 14976-2002, GB 13296-2007, GB 9948-2006 and GB 5310-95
ASTM A312, ASTM A213, ASTM A269 and ASTM A511
ASTM A789 and ASTM A790
JIS 3463 and JIS 3459
DIN 2462, DIN 17458 and DIN 17456
GOST 9941

Surface finish: polishing (180, 220, 240, 320#) and acid pickling

Applications:

General service industries: petroleum, food, chemical, paper, fertilizer, fabric, aviation and nuclear
Fluid, gas and oil transport
Pressure and heat transmission
Construction and ornament
Boiler heat exchanger

Advantages of Floor Heating Heat Exchanger:

High heating efficiency
Big flow volume with low pressure drop
Low fouling

Material: All stainless steel
Max design temperature:208°C
Max. working pressure:3.0MPa

Heat Exchangers Performance of Floor Heating Heat Exchangers:

Features of Boiler Heat Exchangers:

They are built by high heat transfer efficiency tubes, spiral twisted tubes, and smooth shell. The design produced more heat transfer efficiency, high velocities, low pressure drop and low fouling inside of the unit. It makes our heat exchangers a very reliable, efficient and cost effective way to transfer heat indirectly between any solar water heater and floor loops,besides other applications.

Fully Stainless Steel construction, they are good at sanitary water, drinking water, food process and medical process heating or cooling.

Floor heating area from 40 square meter to 1500 square meter

Typical residential application:

In-floor heating
Swimming pools, spas heating
Driveway snowmelts

Typical industrial application:

Oil cooler
Transmission and engine cooler
Boiler sample cooler
Waste water heat recovery
