Product Details:
|
Vehicle Name: | Suction sewage truck | Vehicle Category: | Special Purpose Vehicle |
Chinese Brand: | Lion Brand | English brand : | |
Notice batch : | 226 | Exemption: | No |
Engine | Engine Manufacturer | Displacement (ml) | Power (kw) |
WD615.92 WD615.93 WD615.92E WD615.93E WD615.92C WD615.93C WD615.97C WD615.97E | China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. | 9726 9726 9726 9726 9726 9726 9726 9726 | 196 213 196 213 198 213 221 221 |
Engine brand : | Fuel type: | Diesel (mm) | |
Dimensions: | 10855 * 2500 * 3850 (mm) | Compartment Size : | * * (mm) |
The total mass : | 25000 (Kg) | Payload: | 0 |
Curb weight: | 12870 (Kg) | Rated Quality: | 12000 (Kg) |
Quality Trailer : | (kg) | Semitrailer saddle : | |
Rated capacity : | ( People ) | Cab seats : | ( People ) |
Approach / departure angle : | 15/20 () | Front / rear overhang : | 1500/2780, 1500/2755 (mm) |
Axle load: | 7000 /18000 ( and loading axis ) | Wheelbase: | 5225 +1350,5200 +1400 (mm) |
Number of axes: | 3 | Maximum speed: | 85 (km / h) |
Fuel consumption: | Spring: | 10/ 12 , 4/ 12, 10 / - | |
Number of tires : | 10 | Tire Size: | 11.00-20,11.00 R20 16PR ,12.00-20 16PR, 12.00R20 14PR |
Front track: | 2022,2041 | Rear track: | 1830/ 1830 |
Brake Front: | After braking : | ||
Built before the parade : | After operating system : | ||
Steering Type : | Steering wheel | Starting method: | |
Chassis Emission standard: | GB17691-2005 National , GB3847-2005 | ||
Transmission Type: | According to the standard : | ||
Vin Vehicle Identification Number: | LZZ5BLMH * * * * * * * * * LZZ5BLNH * * * * * * * * * LZZ5BMMH * * * * * * * * * LZZ5BMNH * * * * * * * * * | ||
Logo Enterprises : | Zhejiang Daoming Optics Co., Ltd. | Release date: | 20110609 |
Vehicle Notes : | Tank volume : 22.9 m3 , medium: dry sludge , density: 550 kg / cubic meter , tank dimensions: length 7000 mm ( excluding head ) , diameter 2280 mm . Optional rear overhang caused by different wheelbase difference with the optional chassis cab high roof . protective materials are Q235 steel, side protection with screw connection , after the protective welded connections . protection section height 150mm, cross-sectional width 50mm, the lower edge above ground 545mm. |
ZZ1257M5247C chassis parameters |
HOWO truck chassis | HOWO truck chassis brand ZZ1257M5247CSpecification | |||
Company Name : | China CNHTC Jinan Truck Co., Ltd. | ||
Chassis Type: | ZZ1257M5247C | Chassis Category: | II |
Product Name: | Truck chassis | Product Brand: | HOWO brand |
Zip Code: | 250002 | Catalog number : | 63 |
Specifications: | Length: 10855 Width: 2496 Height: 2958,3563 | ||
Fuel Type: | Diesel fuel | According to the standard : | GB17691-2005 National , GB3847-2005 |
Steering Type : | Steering wheel | ||
Number of axes: | 3 | Wheelbase: | 5225 +1350,5200 +1400 |
Spring: | 10/ 12 , 4/ 12, 10 / - | Number of tires : | 10 |
Tire Size: | 11.00-20,11.00 R20 16PR ,12.00-20 16PR, 12.00R20 14PR | Tread : | Front track Rear track 2022,2041 1830/ 1830 |
The total mass : | 25000 | ||
Curb weight: | 9300,8600 | Quality Trailer : | |
Semitrailer saddle : | Front passenger : | 2 | |
Close to the departure angle: | 16 /16 | Rear suspension : | 1500/ 2780 , 1500/ 2755 |
Maximum speed: | 80,90,102 | ||
Picture: |
HOWO truck chassis | HOWO truck chassis brand ZZ1257M5247CEngine Specification | |||
Engine Model | Engine Manufacturer | Displacement (ML) | Power (ML) |
WD615.92 WD615.93 WD615.92E WD615.93E WD615.92C WD615.93C WD615.97C WD615.97E | China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. China Heavy Duty Truck Group Co., Ltd. | 9726 9726 9726 9726 9726 9726 9726 9726 | 196 213 196 213 198 213 221 221 |
Identification code : | LZZ5BLMH * * * * * * * * * LZZ5BLNH * * * * * * * * * LZZ5BMMH * * * * * * * * * LZZ5BMNH * * * * * * * * * | ||
Other: | Car optional high roof cab , chassis height is 3563mm. The chassis for retrofitting fire truck, wrecker , oilfield job class car, truck , etc. , the total mass of 32000kg, axle load (kg) 7000/25000 ( and loading axis ) . Optional rear axle gear ratio is 4.22 , the maximum speed of 102km / h; optional rear axle gear ratio is 4.8 , the maximum speed of 90km / h. Wheelbase and rear overhang parameter correspondence. Optional WD615.97E, WD615.97C engine , VIN codes are of as LZZ5BLNH * * * * * * * * * (25000kg), LZZ5BMNH * * * * * * * * * (32000kg). Optional WD615.92, WD615.93, WD615.92E, WD615.92C, WD615.93E, WD615.93C engine , VIN codes were as LZZ5BLMH * * * * * * * * * (25000kg), LZZ5BMMH * * * * * * * * * (32000kg). Optional 10 / - suspension , the corresponding curb weight is 8600kg. The car engine is WD615.97C, WD615.97E , the optional speed limiting device , speed limit 80km / h. ABS system model 4460046300 , production enterprises WABCO Vehicle Control Systems ( China ) Co., Ltd. . Installation with satellite positioning function tachograph . |
