Product Details:
Payment & Shipping Terms:
|
| Air Pressure: | 0.4-0.6MPa | Filling Speed: | 30-60 Bottles/min |
|---|---|---|---|
| Filling Accuracy: | ≦±1﹪ | Filling Range: | 50-5000ml |
| Weight: | 800KG | Condition: | New |
| Application: | Liquid Detergent With Chlorine | After-sales Service Provided: | Engineers Available To Service |
| High Light: | Filling line equipment,liquid filling line |
||
Chlorine Detergent Liquid Filling Line 30-60 Bottles/min
Description:
Chlorine Detergent Liquid Filling Line is controlled by computer (PLC),touch screen control panel . It is charactered by long service life element ,easy maintaining ,stable and reliable ,easy operating ,metering accurate and fast .
All the parts which contact with the filling material are made of stainless steel. The surface is polished . It has polished . It has nice appearance ,(in addition ,it may add full close equipment ) This machine also meets to GMPstandard requirement .
Applications:
Chlorine Detergent Liquid Filling Line is suitable for packing ES, SC material with good fluidity. It uses vertical structure with constant liquid level and time which realize the precise filling. It is controlled by the PLC, human interface and easy operation. The machine is equipped with electric scale weight feedback system which makes the volume adjust easier.
* The cylinder drives the diving of the filling nozzle and matched with the variable filling speed which can reduce foaming when filling which can avoid polluting the bottles.
* The latest designed bottle-chuck structure is adopted, convenient adjustment, and reliable structure.
* Optimized Bottle-in and bottle-out control modes: Normal and fast. The fast mode has no delay in bottle-in and out which improves the capacity.
* The material level sensor is used to check the level position under normal running of the machine,plus with high and low level check and alarm device. The level inspection device is made of PTFE, with perfect anti-corrosion feature.
Specifications:
|
Type |
Heads |
Suitable bottle |
Capacity (bottle/hour) |
Precise |
Size of machine (mm) |
Power (KW) |
Power source |
Air source |
Note |
|
SFL -20 |
20 |
Round bottle: |
200ml:8000 |
≤100ml: + -1.5ml 100-500ml: + -2ml 500-1000ml:+ -3ml |
2400*1100*2500 |
1.5 |
220V; 50HZ |
0.6MPa |
|
|
SFL -18 |
18 |
200ml:7000 |
2200*1100*2400 |
1.5 |
|||||
|
SFL -16 |
16 |
200ml:6000 |
2000*1100*2400 |
1.5 |
|||||
|
SFL -12 |
12 |
200ml:5000 |
2000*1100*2400 |
1 |
|||||
|
SFL -8 |
8 |
200ml:3000 |
1800*1100*2400 |
1 |
|||||
|
SFL -6 |
6 |
200ml:2000 |
1500*1100*2200 |
1 |
picture show:
