Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters

Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters
Product Details:
Place of Origin: P.R.China
Brand Name: Ningbo Wasser
Certification: CE,ISO9001,MID
Model Number: LWFN-125B
Application: Agricultural|Irrigation
Body Material: Brass
color: Customized
drive: Magnetic
features: Digital|Accuracy
product name: Industrial Water Meter
Detailed Product Description
High Light:

Irrigation Water Meter

,

agricultural water meter





Multi Jet Clear Reading Industrial Water Meter / Agricultural Irrigation Water Meters





Quick Detail:



Multi Jets, Liquid Sealed;

Optimum accuracy and performance at all times;

Accurate measurement, easy and long term clear reading etc;





Description:



Vane Wheel Liquid Sealed Water Meter For Irrigation  LWFN-125B is used to measure the total quantity of cold potable water which consumed in household or a resident unit, passing through the pipeline.





Applications:



Measuring the volume of cold potable water passing through the pipeline.

Water Temperature: Cold water meter ≤ 40℃, Hot water meter ≤90℃

Water Pressure:≤ 1.6Mpa(16bar)





Specifications:



Main Technical Data

Type

LWFN-125B

Size(mm)

125

Q4(m3/h)

120

Q3(m3/h)

60

Q2(m3/h)

17.6

Q1(m3/h)

11

Min Reading(m3)

0.01

Max Reading(m3)

99999



Dimensions and Weight

Type

LWFN-125B

Size(mm)

125

Length(mm)

400

Width(mm)

250

Height(mm)

280

Connecting Thread(D)

250/210/8*M16

Weight(kg)

33





Competitive Advantage:


1. Liquid Sealed, multi jets, cold water meter

2. brass body

3. ISO standard, MID certification

4.Remote Reading
