Stainless Steel Forged Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance

Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance

Large Image :  Stainless Steel Forged Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance

Product Details:
Place of Origin: CHINA, JAPAN, THAILAND, UK, USA
Brand Name: YUHONG SPECIAL STEEL
Certification: API, PED
Model Number: F304, F304L , F310S, F316L, F317L ,F321, F904L , F44, F51, F53, F60, F61
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: NEGITABLE
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 5DAYS
Payment Terms: T/T, L/C
Supply Ability: 200 TONS PER MONTH
Detailed Product Description
Material: Forged Stainless Steel,Forged Alloy Steel,Forged Carbon Steel Size: 15 NB To 100 NB
Sch. & Class: 3000, 6000 & 9000 LBS Certification: ABS, BV, DNV, LR, GL , KR, NSK, CCS, ISO, TS , PED , GOST
Highlight:

Forged Steel Fitting

,

carbon steel fittings

Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance F304, F304L , F310S, F316L, F317L ,F321, F904L , F44, F51, F53, F60, F61





Forged Steel Elbow : 45deg, 90 deg, 180 deg. A-182/A105 S/W & SCRD,B16.11,

Sr. No. Material Size Sch. & Class Specification Item
1. Forged Stainless Steel 15 NB
To
100 NB
3000, 6000
&
9000 LBS
A-182
S/W & SCRD
ANSI B16.11
  • Elbow - 90o & 45o
  • Tee - Equal & Reducing
  • Union
  • Cross
  • Coupling - Full & Half
  • Socket Reducing
  • CAP
  • Plug-Hex & Square
  • Nipples (Hex/Reducing)
  • Sokolet & Weldolet
  • Bush
  • Fasteners
2. Forged Alloy Steel 15 NB
To
100 NB
3000, 6000
&
9000 LBS
A-182
S/W & SCRD
ANSI B16.11
3. Forged Carbon Steel 15 NB
To
100 NB
3000, 6000
&
9000 LBS
A-105
S/W & SCRD
ANSI B16.11






Stainless Steel in Grade ASTM A 182 F :- 304, 304L, 304H, 316, 316L, 316LN, 316Ti, 309, 310S, 317L, 321, 347, 410, 420, 440C Etc
Alloy Steel in Grade ASTM A 182 :- F5, F9, F11, F12, F21, F22 & F91.
Othe rGrade Available :- A-350 LF2
Other Forms :- Compression Fitting / Instrumentation / Hydraulic Fitting & Also As Per Drawing
Other Material like Non Ferrous Metals & Nickel Base Alloys :- Fittings are also available in Copper (Dow), Brass, Aluminium, Cupro Nickel (90/10, 70/30), Hastelloy (C-276), Nickel (200, 201, 205), Monel (K400, K500), Inconel (600, 800), Alloy 20, Duplex, Phosphorus Bronze (90/10, PB2) Etc. as per ASTM, ASME, BS, IS & DIN Standard
Test Certificate :-
  • Manufacturer Test Certificate / Under Third Party Inspection .
  • with Excise Gate Pass to avail Modvat benefit.



Product Pictures and Drawings
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 0
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 1
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 2
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 3
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 4
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 5
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 6
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 7
90 Degree Elbow (SW)
45 Degree Elbow (SW)
Tee (SW)
Lateral (SW)
Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 8 Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 9 Stainless Steel Forged  Fitting, ASME B16.11,. MSS SP-79, and MSS SP-83. Superior Corrosion Resistance 10
Cross (SW) Socket Weld Fittings
Socket Weld Dimensional Data
1/8" to 4" class 3000 socket weld, 1/8" to 4" class 6000 socket weld, 1/2" to 2 " class 9000 socket weld
Class 3000   1/8 1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 4
A 7/8 7/8 31/32 1 1/8 1 5/16 1 1/2 1 3/4 2 2 3/8 3 3 3/8 4 3/16
B 29/32 29/32 1 1/16 1 5/16 1 9/16 1 27/32 2 7/32 2 1/2 3 1/32 3 11/16 4 5/16 5 3/4
C 0.420 0.555 0.690 0.855 1.065 1.330 1.675 1.915 2.406 2.906 3.535 4.545
D 3/8 3/8 3/8 3/8 1/2 1/2 1/2 1/2 5/8 5/8 5/8 3/4
E 7/16 7/16 17/32 5/8 3/4 7/8 1 1/16 1 1/4 1 1/2 1 5/8 2 1/4 2 5/8

Class 6000   1/8 1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 4
A - - - 1 5/16 1 1/2 1 3/4 2 2 3/8 2 1/2 3 1/4 3 3/4 4 1/2
B - - - 1 9/16 1 27/32 2 7/32 2 1/2 3 1/32 3 11/32 4 4 3/4 6
C - - - 0.855 1.065 1.330 1.675 1.915 2.406 2.906 3.535 4.545
D - - - 3/8 1/2 1/2 1/2 1/2 5/8 5/8 5/8 3/4
E - - - 3/4 7/8 1 1/16 1 1/4 1 1/2 1 5/8 2 1/4 2 1/2 2 3/4

Class 9000   1/8 1/4 3/8 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 4
A - - - 1 1/2 1 3/4 2 2 3/8 2 1/2 3 - - -
B - - - 1 27/32 2 7/32 2 1/2 3 1/32 3 11/32 3 11/16 - - -
C - - - 0.855 1.065 1.330 1.675 1.915 2.406 - - -
D - - - 3/8 1/2 1/2 1/2 1/2 5/8 - - -
E - - - 1 1 1/8 1 1/4 1 3/8 1 1/2 2 1/8 - - -



ASME/ANSI B16.1 - 1998 - Cast Iron Pipe Flanges and Flanged Fittings

This Standard for Classes 25, 125, 250 Cast Iron Pipe Flanges and Flanged Fittings covers:

(a) pressure-temperature ratings,

  • (b) sizes and method of designating openings of reducing fittings,
  • (c) marking,
  • (d) minimum requirements for materials,
  • (e) dimensions and tolerances,
  • (f) bolt, nut, and gasket dimensions and
  • (g) tests.

ASME/ANSI B16.3 - 1998 - Malleable Iron Threaded Fittings

This Standard for threaded malleable iron fittings Classes 150, and 300 provides requirements for the following:

  • (a) pressure-temperature ratings
  • (b) size and method of designating openings of reducing fittings
  • (c) marking
  • (d) materials
  • (e) dimensions and tolerances
  • (f) threading
  • (g) coatings

ASME/ANSI B16.4 - 1998 - Cast Iron Threaded Fittings

This Standard for gray iron threaded fittings, Classes 125 and 250 covers:

  • (a) pressure-temperature ratings
  • (b) size and method of designating openings of reducing fittings
  • (c) marking
  • (d) material
  • (e) dimensions and tolerances
  • (f) threading, and
  • (g) coatings

ASME/ANSI B16.5 - 1996 - Pipe Flanges and Flanged Fittings

The ASME B16.5 - 1996 Pipe Flanges and Flange Fittings standard covers pressure-temperature ratings, materials, dimensions, tolerances, marking, testing, and methods of designating openings for pipe flanges and flanged fittings.

The standard includes flanges with rating class designations 150, 300, 400, 600, 900, 1500, and 2500 in sizes NPS 1/2 through NPS 24, with requirements given in both metric and U.S units. The Standard is limited to flanges and flanged fittings made from cast or forged materials, and blind flanges and certain reducing flanges made from cast, forged, or plate materials. Also included in this Standard are requirements and recommendations regarding flange bolting, flange gaskets, and flange joints.

ASME/ANSI B16.9 - 2001 - Factory-Made Wrought Steel Buttwelding Fittings

This Standard covers overall dimensions, tolerances, ratings, testing, and markings for wrought factory-made buttwelding fittings in sizes NPS 1/2 through 48 (DN 15 through 1200).

ASME/ANSI B16.10 - 2000 - Face-to-Face and End-to-End Dimensions of Valves

This Standard covers face-to-face and end-to-end dimensions of straightway valves, and center-to face and center-to-end dimensions of angle valves. Its purpose is to assure installation interchangeability for valves of a given material, type size, rating class, and end connection

ASME/ANSI B16.11 - 2001 - Forged Steel Fittings, Socket-Welding and Threaded

This Standard covers ratings, dimensions, tolerances, marking and material requirements for forged fittings, both socket-welding and threaded.

ASME/ANSI B16.12 - 1998 - Cast Iron Threaded Drainage Fittings

This Standard for cast iron threaded drainage fittings covers:

  • (a) size and method of designating openings in reducing fittings
  • (b) marking
  • (c) materials
  • (d) dimensions and tolerances
  • (e) threading
  • (f) ribs
  • (g) coatings
  • (h) face bevel discharge nozzles, input shafts, base plates, and foundation bolt holes (see Tables 1 and 2).

ASME/ANSI B16.14 - 1991 - Ferrous Pipe Plugs, Bushings and Locknuts with Pipe Threads

This Standard for Ferrous Pipe Plugs, Bushings, and Locknuts with Pipe Threads covers:

  • (a) pressure-temperature ratings:
  • (b) size;
  • (c) marking;
  • (d) materials;
  • (e) dimensions and tolerances;
  • (f) threading; and
  • (g) pattern taper.

ASME/ANSI B16.15 - 1985 (R1994) - Cast Bronze Threaded Fittings

This Standard pertains primarily to cast Class 125and Class 250 bronze threaded pipe fittings. Certain requirements also pertain to wrought or cast plugs, bushings, couplings, and caps. This Standard covers:

  • (a) pressure-temperature ratings;
  • (b) size and method of designating openings of reducing pipe fittings;
  • (c) marking;
  • (d) minimum requirements for casting quality and materials;
  • (e) dimensions and tolerances in U.S. customary and metric (SI) units;
  • (f) threading.

ASME/ANSI B16.18 - 1984 (R1994) - Cast Copper Alloy Solder Joint Pressure Fittings

This Standard for cast copper alloy solder joint pressure fittings designed for use with copper water tube, establishes requirements for:

  • (a) Pressure-temperature ratings;
  • (b) Abbreviations for end connections;
  • (c) Sizes and method of designating openings of fittings;
  • (d) Marking;
  • (e) Material;
  • (f) Dimensions and tolerances; and
  • (g) Tests.

ASME/ANSI B16.20 - 1998 - Metallic Gaskets for Pipe Flanges-Ring-Joint, Spiral-Would, and Jacketed

This standard covers materials, dimensions, tolerances, and markings for metal ring-joint gaskets, spiral-wound metal gaskets, and metal jacketed gaskets and filler material. These gaskets are dimensionally suitable for used with flanges described in the reference flange standards ASME/ANSI B16.5, ASME B16.47, and API-6A. This standard covers spiral-wound metal gaskets and metal jacketed gaskets for use with raised face and flat face flanges. Replaces API-601 or API-601.

ASME/ANSI B16.21 - 1992 - Nonmetallic Flat Gaskets for Pipe Flanges

This Standard for nonmetallic flat gaskets for bolted flanged joints in piping includes:

  • (a) types and sizes;
  • (b) materials;
  • (c) dimensions and allowable tolerances.

ASME/ANSI B16.22 - 1995 - Wrought Copper and Copper Alloy Solder Joint Pressure Fittings

The Standard establishes specifications for wrought copper and wrought copper alloy, solder-joint, seamless fittings, designed for use with seamless copper tube conforming to ASTM B 88 (water and general plumbing systems), B 280 (air conditioning and refrigeration service), and B 819 (medical gas systems), as well as fittings intended to be assembled with soldering materials conforming to ASTM B 32, brazing materials conforming to AWS A5.8, or with tapered pipe thread conforming to ASME B1.20.1. This Standard is allied with ASME B16.18, which covers cast copper alloy pressure fittings. It provides requirements for fitting ends suitable for soldering. This Standard covers:

  • (a) pressure temperature ratings;
  • (b) abbreviations for end connections;
  • (c) size and method of designating openings of fittings;
  • (d) marking;
  • (e) material;
  • (f) dimension and tolerances; and
  • (g) tests.

ASME/ANSI B16.23 - 1992 - Cast Copper Alloy Solder Joint Drainage Fittings (DWV)

The Standard establishes specifications for cast copper alloy solder joint drainage fittings, designed for use in drain, waste, and vent (DWV) systems. These fittings are designed for use with seamless copper tube conforming to ASTM B 306, Copper Drainage Tube (DWV), as well as fittings intended to be assembled with soldering materials conforming to ASTM B 32, or tapered pipe thread conforming to ASME B1.20.1. This standard is allied with ASME B16.29, Wrought Copper and Wrought Copper Alloy Solder Joint Drainage Fittings - DWV. It provides requirements for fitting ends suitable for soldering. This standard covers:

  • (a) description;
  • (b) pitch (slope);
  • (c) abbreviations for end connections;
  • (d) sizes and methods for designing openings for reducing fittings;
  • (e) marking;
  • (f) material; and
  • (g) dimensions and tolerances.

ASME/ANSI B16.24 - 1991 (R1998) - Cast Copper Alloy Pipe Flanges and Flanged Fittings

This Standard for Classes 25, 125, 250, and 800 Cast Iron Pipe Flanges and Flanged Fittings covers:

  • (a) pressure temperature ratings,
  • (b) sizes and methods of designating openings for reduced fittings,
  • (c) marking,
  • (d) minimum requirements for materials,
  • (e) dimensions and tolerances,
  • (f) bolt, nut, and gasket dimensions, and
  • (g) tests.

ASME/ANSI B16.25 - 1997 - Buttwelding Ends

  • The Standard covers the preparation of butt welding ends of piping components to be joined into a piping system by welding. It includes requirements for welding bevels, for external and internal shaping of heavy-wall components, and for preparation of internal ends (including dimensions and tolerances). Coverage includes preparation for joints with the following.
  • (a) no backing rings;
  • (b) split or non continuous backing rings;
  • (c) solid or continuous backing rings;
  • (d) consumable insert rings;
  • (e) gas tungsten are welding (GTAW) of the root pass. Details of preparation for any backing ring must be specified in ordering the component.

ASME/ANSI B16.26 - 1988 - Cast Copper Alloy Fittings for Flared Copper Tubes

This standard for Cast Copper Alloy Fitting for Flared Copper Tubes covers:

  • (a) pressure rating;
  • (b) material;
  • (c) size;
  • (d) threading;
  • (e) marking.

ASME/ANSI B16.28 - 1994 - Wrought Steel Buttwelding Short Radius Elbows and Returns

This Standard covers ratings, overall dimensions, testing, tolerances, and markings for wrought carbon and alloy steel buttwelding short radius elbows and returns. The term wrought denotes fittings made of pipe, tubing, plate, or forgings.

ASME/ANSI B16.29 - 1994 - Wrought Copper and Wrought Copper Alloy Solder Joint Drainage Fittings (DWV)

The standard for wrought copper and wrought copper alloy solder joint drainage fittings, designed for use with copper drainage tube, covers:

  • (a) Description,
  • (b) Pitch (slope),
  • (c) Abbreviations for End Connections,
  • (d) Sizes and Method of Designating Openings for Reducing Fittings,
  • (e) Marking,
  • (f) Material,
  • (g) Dimensions and Tolerances.

ASME/ANSI B16.33 - 1990 - Manually Operated Metallic Gas Valves for Use in Gas Piping Systems Up to 125 psig

General This Standard covers requirements for manually operated metallic valves sizes NPS 1.2 through NPS 2, for outdoor installation as gas shut-off valves at the end of the gas service line and before the gas regulator and meter where the designated gauge pressure of the gas piping system does not exceed 125 psi (8.6 bar). The Standard applies to valves operated in a temperature environment between .20 degrees F and 150 degrees F (.29 degrees C and 66 degrees C). Design This Standard sets forth the minimum capabilities, characteristics, and properties, which a valve at the time of manufacture must possess, in order to be considered suitable for use in gas piping systems.

ASME/ANSI B16.34 - 1996 - Valves - Flanged, Threaded, and Welding End

This standard applies to new valve construction and covers pressure-temperature ratings, dimensions, tolerances, materials, nondestructive examination requirements, testing, and marking for cast, forged, and fabricated flanged, threaded, and welding end, and wafer or flangeless valves of steel, nickel-base alloys, and other alloys shown in Table 1. Wafer or flangeless valves, bolted or through-bolt types, that are installed between flanges or against a flange shall be treated as flanged end valves.

ASME/ANSI B16.36 - 1996 - Orifice Flanges

This Standard covers flanges (similar to those covered in ASME B16.5) that have orifice pressure differential connections. Coverage is limited to the following:

  • (a) welding neck flanges Classes 300, 400, 600, 900, 1500, and 2500
  • (b) slip-on and threaded Class 300
  • Orifice, Nozzle and Venturi Flow Rate Meters

ASME/ANSI B16.38 - 1985 (R1994) - Large Metallic Valves for Gas Distribution

The standard covers only manually operated metallic valves in nominal pipe sizes 2 1/2 through 12 having the inlet and outlet on a common center line, which are suitable for controlling the flow of gas from open to fully closed, for use in distribution and service lines where the maximum gage pressure at which such distribution piping systems may be operated in accordance with the code of federal regulations (cfr), title 49, part 192, transportation of natural and other gas by pipeline; minimum ety standard, does not exceed 125 psi (8.6 bar). Valve seats, seals and stem packing may be nonmetallic.

ASME/ANSI B16.39 - 1986 (R1998) - Malleable Iron Threaded Pipe Unions

This Standard for threaded malleable iron unions, classes 150, 250, and 300, provides requirements for the following:

  • (a) design
  • (b) pressure-temperature ratings
  • (c) size
  • (d) marking
  • (e) materials
  • (f) joints and seats
  • (g) threads
  • (h) hydrostatic strength
  • (i) tensile strength
  • (j) air pressure test
  • (k) sampling
  • (l) coatings
  • (m) dimensions

ASME/ANSI B16.40 - 1985 (R1994) - Manually Operated Thermoplastic Gas

The Standard covers manually operated thermoplastic valves in nominal sizes 1.2 through 6 (as shown in Table 5). These valves are suitable for use below ground in thermoplastic distribution mains and service lines. The maximum pressure at which such distribution piping systems may be operated is in accordance with the Code of Federal Regulation (CFR) Title 49, Part 192, Transportation of Natural and Other Gas by Pipeline; Minimum ety Standards, for temperature ranges of .20 deg. F to 100 deg. F (.29 deg. C to 38 deg. C). This Standard sets qualification requirements for each nominal valve size for each valve design as a necessary condition for demonstrating conformance to this Standard. This Standard sets requirements for newly manufactured valves for use in below ground piping systems for natural gas [includes synthetic natural gas (SNG)], and liquefied petroleum (LP) gases (distributed as a vapor, with or without the admixture of air) or mixtures thereof.

ASME/ANSI B16.42 - 1998 - Ductile Iron Pipe Flanges and Flanged Fittings, Classes 150 and 300

The Standard covers minimum requirements for Class 150 and 300 cast ductile iron pipe flanges and flanged fittings. The requirements covered are as follows:

  • (a) pressure-temperature ratings
  • (b) sizes and method of designating openings
  • (c) marking
  • (d) materials
  • (e) dimensions and tolerances
  • (f) blots, nuts, and gaskets
  • (g) tests

ASME/ANSIB16.44 - 1995 - Manually Operated Metallic Gas Valves for Use in House Piping Systems

This Standard applies to new valve construction and covers quarter turn manually operated metallic valves in sizes NPS 1/2-2 which are intended for indoor installation as gas shutoff valves when installed in indoor gas piping between a gas meter outlet & the inlet connection to a gas appliance.

ASME/ANSI B16.45 - 1998 - Cast Iron Fittings for Sovent Drainage Systems

The Standard for cast iron drainage fittings used on self-aerating, one-pipe Solvent drainage systems, covers the following:

  • (a) description
  • (b) sizes and methods for designating openings for reducing fittings
  • (c) marking
  • (d) material
  • (e) pitch
  • (f) design
  • (g) dimensions and tolerances
  • (h) tests

ASME/ANSI B16.47 - 1996 - Large Diameter Steel Flanges: NPS 26 through NPS 60

This Standard covers pressure-temperature ratings, materials, dimensions, tolerances, marking, and testing for pipe flanges in sizes NPS 26 through NPS 60 and in ratings Classes 75, 150,0300, 400, 600, and 900. Flanges may be cast, forged, or plate (for blind flanges only) materials. Requirements and recommendations regarding bolting and gaskets are also included.

ASME/ANSI B16.48 - 1997 - Steel Line Blanks

The Standard covers pressure-temperature ratings, materials, dimensions, tolerances, marking, and testing for operating line blanks in sizes NPS 1/2 through NPS 24 for installation between ASME B16. 5 flanges in the 150, 300, 600, 900, 1500, and 2500 pressure classes.

ASME/ANSI B16.49 - 2000 - Factory-Made Wrought Steel Buttwelding Induction Bends for Transportation and Distribution Systems

This Standard covers design, material, manufacturing, testing, marking, and inspection requirements for factory-made pipeline bends of carbon steel materials having controlled chemistry and mechanical properties, produced by the induction bending process, with or without tangents. This Standard covers induction bends for transportation and distribution piping applications (e.g., ASME B31.4, B31.8, and B31.11) Process and power piping have differing requirements and materials that may not be appropriate for the restrictions and examinations described herein, and therefore are not included in this Standard.












Contact Details
Beijing Water Meter Co.,Ltd.

Contact Person: Miss.

Tel: 10-65569770

Fax: 86-10-8563-2312

Send your inquiry directly to us (0 / 3000)
