Seamless Copper Nickel Tube 2015Hot Sale C70600, C71500 70/30

Large Image : Seamless Copper Nickel Tube 2015Hot Sale C70600, C71500 70/30

Product Details:

Place of Origin:	China/Japan/Germany
Brand Name:	TOBO/TPCO/TISCO/VALIN/METAL
Certification:	ISO/PED/TUV/SGS/LR/BV
Model Number:	Seamless copper nickel tube CUNI pipe C70600, C71500 2015 Hot sale 70/30 Copper nickel tube /0/10 Copper nickel tube

Payment & Shipping Terms:

Minimum Order Quantity:	1M
Price:	USD
Packaging Details:	PLY-WOODCASE
Delivery Time:	5-65workdays
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	30000TON/YEAR

Contact Now

Detailed Product Description

Standard:	C70600, C71500 ASTM B111 ASTM B466, B359	Length:	Single Random, Double Random & Cut Length
End:	These Pipes Have Plain End, Beveled End, Threaded And Features Like Hot Dipped Galvanizing, Epoxy & Fbe Coating And Electro Polish	Grade:	C70600, C71500 ASTM B111 ASTM B466, B359
Color:	Black Or Red	Types:	Seamless
ASTM:	C70600, C71500 ASTM B111 ASTM B466, B359	Form:	Round, Square, Rectangular, Hydraulic Etc
Highlight:	copper nickel tubing , copper nickel pipe

Seamless copper nickel tube CUNI pipe C70600, C71500 2015 Hot sale 70/30 Copper nickel tube /0/10 Copper nickel tube

Copper nickel tube, ASTMB111,C70600,manily be used in the heat exchanger,ship building ,power station and so on;

1.   Standard Applied: ASTM B111 (ASTM B466, ASTM B359, ASTM 395), JIS H3300, BS EN 12451, EN 12449, GB/T8890 etc.

2.   Quality : bright ,clean and smmoth in the surface; No burr in the end ; Eddy Current test is ok ;

3. Specification :   O.D 2mm to O.D 40mm;     Length can up to 12m;

4. The brass tubes are widely used in Steam Turbines, Seawater Desalination Equipments, Petrochemical Plants, Power Plants, Coolers, Boiler, Water Evaporators, Oil Refineries, and Shipbuilding.

5. Material Designation Applied: C71500, C70600, C71640, C68700, C44300, C26130 etc.

6. Material Brand:

Grade	USA	U.K	Germany	Japan
China BG	ASTM	BS	DIN	JIS H
BFe10-1-1	C70600	CN102	CuNi10Fe1Mn	C7060
BFe30-1-1	C71500	CN107	CuNi30Mn1Fe	C7150
HAL77-2	C68700	CZ110	CuZn22Al	C6870
HSn70-1	C44300	CZ111	CuZn28Sn1	C4430
H68A	C26130	CZ126	-----	-----

Series 1 Copper Nickel Tubes	Standard Grade					Dimensions (mm)
Material	EN12451	ASTM B111	ASME SB111	JIS H3300	BS2871 Part3	OD Range	WT Range
90/10 Copper Nickel Alloy C70600	CuNi10Fe1Mn CW352H	C70600	C70600	C7060	CN102	4~50	0.2~5
70/30 Copper Nickel Alloy C71500	CuNi30Mn1Fe CW354H	C71500	C71500	C7150	CN107	4~50	0.2~5
Copper Nickel Iron Manganese Alloy C71640	CuNi30Fe2Mn2 CW353H	C71640	C71640	C7164	CN108	4~50	0.2~5

Series 2 Brass Tube	Standard Grade					Dimensions (mm)
Material	EN12451	ASTM B111	ASME SB111	JIS H3300	BS2871 Part3	OD Range	WT Range
Admiralty Brass Alloy C44300	CuZn28Sn1As CW706R	C44300	C44300	C4430	CZ111	4~50	0.2~5
Aluminium Brass Alloy C68700	CuZn20Al2As cw702R	C68700	C68700	C6870	CZ110	4~50	0.2~5

Series 2 Brass Tube	Standard Grade		Dimensions (mm)
Material	ASTM B135	JIS H3300	OD Range	WT Range
65/35 Copper Zinc Alloy C27000	C27000	C2700	4~50	0.2~5
63/37 Copper Zinc Alloy C27200	C27200	C2720	4~50	0.2~5

Series 3 Copper C12200	Standard Grade					Dimensions (mm)
Material	EN12451	ASTM B111	ASME SB111	JIS H3300	BS2871 Part3	OD Range	WT Range
Copper C12200	Cu-DHP	C12200	C12200	C1220	C106	4~50	0.2~5

Series 4 Nickel and Nickel Alloys Tubes	UNS N02200, N04400, N06600, N08800, Size range: OD 6.0~100mm, WT 0.5~8.0mm, up to 15 meters.

Series 5 High Effecient Tubes	Low fin tubes, corrugated tubes.
Remarks:	Dimensions of our normal product range, we are always trying to improve our range so please contact us if you are looking for other dimension.

Eddy current test

Direct-reading spectrometer

Ultrasonic detector

hydraulic test equipment

Chemistry laboratory

Universal testing machine

Universal testing machine

Hardness tester

Metallography microscope imported

Micro-analysis

Chemical analysis
