Construction NDT Equipment Cement Test Hammer , Cement Hardness Tester

Name: Construction NDT Equipment Cement Test Hammer , Cement Hardness Tester
Brand: SRI
SKU: AL-150N
Price: 250 USD
Availability: InStock
Rating: 4.6 (160 reviews)

Large Image : Construction NDT Equipment Cement Test Hammer , Cement Hardness Tester

Product Details:

Place of Origin:	China
Brand Name:	SRI
Certification:	ISO9001:2008
Model Number:	AL-150N

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	250USD
Packaging Details:	Standard exporting package
Delivery Time:	5 working days after received your payment
Payment Terms:	T/T, Paypal, Western Union
Supply Ability:	500sets/month

Contact Now

Detailed Product Description

Warranty Period:	24months	Kinetic Energy:	2.207 J (0.225 KGF. M)
Measuring Range:	20-60Mpa	Net Weight:	1.1kg
Steel Anvil Rate Constant Value:	80 + 2	Test Material:	Cement/Concrete
Display:	Pointer
High Light:	NDT Testing Equipment , non destructive testing instruments

Construction NDT Equipment Cement Test Hammer , Cement Hardness Tester

Description

The AL-150N Cement Hardness Tester is designed according with the JGJ/T23-2001 technical codes HX-225 type cement hardness tester for testing and-mpa within the scope of the concrete compressive strength, the system standard energy for 2.207J, and value system as pointer direct reading type medium, the cement hardness tester execute GB9138-88 and JJG817-1993 national metrological verification code standards, by the China construction science research institute producer. Cement hardness tester is suitable for testing the general construction, Bridges and various propose member (plate and beam, column, bridge) strength.

Features

Center guide adopts imported materials, high accuracy, resistance to wear and tear.
Shell is made of super hard aluminum, avoid on-site damage equipment, prolong service life.
Pointer block the external type spring coil structure, convenient for friction adjustment, and can guarantee pointer shaft and pointer slider
Friction force uniform, to ensure the accuracy of the instrument.

Technical specifications

Measurement range	20 ~ 60 Mpa
Impact energy	2.207 J (0.225 KGF. M)
Pointer length	20.0 + / - 0.2 (mm)
Pointer friction	0.65 + / - 0.15 (N)
Pointer to the largest system static friction force	0.5 ~ 0.8 N
Just drill rate constant mean	80 + 2
Bomb strike rod end spherical radius	25 + / - 1.0 (mm)
Bomb strike tension spring stiffness	7.85 + / - 0.40 (N/cm)
Play with the hammer decoupling position	scale line "100" ruling place
Bomb strike tension spring working length	0.3 mm (mm) 61.5.0
Play with the hammer dive location	scale "0" place
Steel anvil rate constant value	80 + 2
Size	270x55x55mm
Weight	1040 g (including battery)
