Product Details:
Payment & Shipping Terms:
|
| Product Name: | Seamless Carbon Steel Tube | Material: | Carbon Steel |
|---|---|---|---|
| Section Shape: | Round | Technique: | Seamless |
| Delivery Condition: | Annealed, Normalized, Tempered | Application: | For High Temperature |
| High Light: | seamless carbon steel pipe,carbon seamless steel pipe |
||
Detailed introduction:
Seamless Pipe
Structure Pipe
Pipe for Liquid Transportation
Tube for Ship Building
Product Name:
Seamless steel pipe
Seamless steel pipe for liquid transport :Applicable to transport liquid, gas, oil etcMechanical
seamless steel tubing: Applicable to the general structure, mechanical structure with seamless steel tubes
Standard
GB/T8162 , GB/T8163 ,ASTM A53 ,ASTM A106 ,DIN1629 , API 5L
Steel Grade
GB/T8162 , GB/T8163:10#, 20#, 35#, 45#, 16MN(Q345B)
ASTM A53 GR. A , GR. B, GR. C
ASTM A106 GR. A , GR. B, GR. C
DIN 162 St 37.0, St 44.0, St 52.0
API 5L A B X42,X46, X52, X60, X65, X70, X80
ASTM A106 GrB seamless steel pipe
| China GB | ASTM | DIN 17175 |
| 10# |
ASTM A106 Gr.A ASTM A53 Gr.A ASTM A179-C ASTM A214-C ASTM A192 |
St 37-2 St 35.8 St 35.4 |
| 20# |
ASTM A106 Gr.B ASTM A53 Gr.B ASTM A315 Gr.B ASTM A210-A-1 |
St 42 St 45 |
| 16Mn | ASTM A210-C |
St 52.4 St 52.3 St 52
|
| 45# | ASTM 1045 | CK45 |
| Products | OD | W.T. | Standard | Length | |
| Seamless pipe | 1/2" to 24" | SCH20,30,40,60,STD XS,80 | ASTM A106/API 5L GR.B | 5.8m,24m, | |
| ASTM A53Gr.B | 5m to 24m random | ||||
| Pipe line | 3" to 18" | SCH20,30,40,60,STD XS | API5LGR.B/X42,X52,X60 | 5.8m,24m, | |
| 5m to 24m random | |||||
| ERW Steel pipe | 1" to 28" | SCH20,30,40,60,STD XS,80 | ASRM A53GR.B | 5.8m,24m, | |
| 5m to 24m random | |||||
| Spiral steel pipe | 8" to 36" | SCH20,30,40,60,STD XS,80 | AY/T5037-2001 | 5.8m,6m, | |
| 5m to 24m random | |||||
Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield
strength, Elongation), Technical Properties (Flattening Test, Flaring Test, Bending Test, Hardness Test,
Blow Test, Impact Test etc), Exterior Size Inspection, Nondestructive Test (Ultrasonic flaw detector, Eddy
current flaw detector), Hydrostatic Test.,
