Plastic Resident Mechanical Water Meter / Drinking Water Measuring Instrument

Plastic Residential Mechanical Water Meter For Drinking Water Measuring

Description:
Drinking Water Measuring Instrument LYH-8

Quick Detail:

1. Type name:Drinking water measuring instrument
2. Model No.: LYH-8
3. Standard :ISO 4064 Class C
4. Material: Stainless steel or plastic body
5. Feature :High accuracy ,small starting flow rate
6. Horizontal installation



Product features:

Adopt volumetric rotary piston principle of measurement with conformity to ISO4064 C
Good looking
Vacuum sealed register ,and it separated from water to ensure a clear reading in long term service
Available with stainless steel and plastic body on request


Installation requirements:



1. Meter should be installed in horizontal position with the register face upwards
2. Pipe line must be flushed before installation
3. The meter should be constantly full of water during operation



Main Technical data




Maximum permissible error:

In the lower zone from Qmin inclusive up to but excluding Qt is ±5%
In the upper zone from Qt inclusive up to and including Qs is ±2%


Working Condition:

Water temperature:0℃≤t≤40℃ (For cold water meter)
Water pressure: ≤0.6bar


Specifications:




Competitive Advantage:

 Reasonable price with good quality
 Long time guarantee
 100% tested
 On time delivery
