Explosion-Proof Ultraviolet Water Purification Uv Light Sterilization , Large Capacity

Explosion-Proof Ultraviolet Water Purification Uv Light Sterilization , Large Capacity
Explosion-Proof Ultraviolet Water Purification Uv Light Sterilization , Large Capacity

Large Image :  Explosion-Proof Ultraviolet Water Purification Uv Light Sterilization , Large Capacity

Product Details:
Place of Origin: China
Brand Name: YLD
Certification: SGS
Model Number: YLC-1000
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: with plywood case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or L/C or western Union
Supply Ability: 3,000 units per month
Detailed Product Description
Product Name: UV Sterilizer Flow Rate: 20,000 LPH
Inlet And Outlet Diameter: 21/2 Inch Power: 240W
Service Life Of The UV: More Than 9000 Hours Power Supply: 380V/220V/110V 50Hz/60Hz
Connection Mode: Flange Working Pressure: 0.6Mpa
High Light:

ultraviolet water sterilizer

,

water uv sterilizer

Explosion-Proof Ultraviolet Water Purification Uv Light Sterilization , Large Capacity



    Ultraviolet Water Purifiers

Ultraviolet (UV) water purification systems are thought to offer the most cost-effective way of protecting residential drinking water against biological contaminants. UV purification

 systems can be used to protect against water-borne viruses, bacteria, molds and pathogenic disease-causing microorganisms such as giardia and cryptosporidium. Even viruses such as the hepatitis

virus, which are known to be highly resistant to chlorine-treated water, can be relatively easily eliminated through UV treatment.

What does a UV sterilizer do?

A UV sterilizer is used to control infections by stopping the spread of microorganisms from one

 fish/coral/invertebrate to another through the water. It is also used in pond applications to control

free-floating algae. When operated correctly, free-floating microorganisms will be killed by the UV light.

Note that the organisms must be in the water

 that flows to the UV sterilizer. The UV light has no residual effect and will not kill organisms

attached to fish (e.g., adult stage of ich) or rocks (e.g., algae).

How do UV sterilizers work?

The UV sterilizer utilizes a germicidal fluorescent lamp that produces light at a wavelength of

approximately 254 nanometers (2537 Angstroms). The water with the bacteria/algae passes

over the bulb (or around the bulb if a quartz sleeve is used) and is irradiated with this wavelength.

 As the light penetrates the bacteria/algae, it mutates the DNA (genetic material), preventing

growth/multiplication of the organism.





Application



1.Food processing industry, including juices, milk, drinks, beer, practical oil  and canned food.

2.Electronic industry.
3.Hospitals, various laboratory and high levels of pathogenic body water disinfection.

4.Households building, residential, office buildings, hotels, restaurants, water factories.
5.Purification and disinfection of shellfish, fish cleaning and disinfection

6.Military camp, field water supply system
7.Urban wastewater disinfection.
8.Swimming pool, other recreational water disinfection
9.Thermal power, nuclear power plant  industrial, central air conditioning system cooling water.
10.Biological, chemical and pharmaceutical, cosmetics for the production of cooling water.
11.Sea water, fresh water breeding, aquaculture  water

12.Agricultural water disinfection





Working principle:



The device adopts a special high strength non ozone ultraviolet sterilizing lamp and stainless

steel barrel body odor whose inner wall specially treated by micro carbon martensite, outer side

of the barrel body with a special polishing processing, then the pretreated water flows in the tube, i

t will receive enough line volume of ultraviolet irradiation 253.7nm, which shows excellent germicidal

efficacy, but also effectively reduces the influence on ultra pure water.





Optimal service condition:



As UV is a short- wavelength light wave, it has low radiant energy and weak penetrating power

and can only kill the microorganisms it directly radiates on. Therefore, in order to enhance the

bacteria-killing efficiency and ensure the security of drinking water, the incoming water into the

sterilizer must meet the following standard, (and if exceeding the following standard, the killing

efficiency may be affected).



Total iron content

Less than 0.3ppm(0.3mg/L)

H2S

Less than 0.05ppm(0.05mg/L)

Total suspended matter

Less than 10 mg/L

Manganese content

Less than 0.05 mg/L

Water hardness

Less than 120 mg/L

Chroma

Less than 15centigrade

Water Temp.

5-60Centigrade

PH value

6.5-8

Interface type

flange or thread



Product features:



1. SS304 or SS316 stainless steel reactor.

2. Quartz sleeve to ensure the best working temperature.

3. Comprehensive sterilization, efficient and fast, sterilization rate is up to 99.9%.

4. High output, physical sterilization, without negative effects, without secondary pollution.

5. Full stainless steel shell, adopts European technology, smooth inner wall, without blind zone.

6. Equipment is cleaning and polishing, applicable to high purifying environment.

7. The electrical device is configured to apply in the market around the world.

8. Has special design, and operates very conveniently.



model

capacity

Power

inlet-outlet

reactor

panel

Anchor

G weight



m³/hour

watt

mm

L×W×H

cm

screw

Kg

YLCn-005

0.3

16

1/2″

30×6×11

without

without

5

YLCn-008

1

25

1/2″

47×6.3×11

without

without

10

YLCn-050

2

40

1″

100×9×20

Φ8.9×25

(d×L)

69×4×Φ1

25

YLCn-150

6

80

1+1/4″

100×11×23



69×4×Φ1

30

YLCn-200

8

120

1+1/2″

100×15.9×30

Φ8.9×45

(d×L)

69×7×Φ1

35

YLCn-300

12

160

2″

100×15.9×32



69×7×Φ1

40

YLC-050

2

40

DN25/1″

100×8.9×30

25×30×12

(W×H×D)

60×4×Φ1

45

YLC-150

6

80

DN32/11/4″

100×10.8×30



60×4×Φ1

50

YLC-200

8

120

DN40/11/2″

100×15.9×40



60×7×Φ1

60

YLC-300

12

160

DN50/2″

100×15.9×40



60×7×Φ1

70

YLC-360

15

200

DN65/21/2″

100×15.9×40



60×7×Φ1

120

YLC-500

20

240

DN65/21/2″

100×21.9×50



60×11×Φ1.2

130

YLC-600

25

280

DN80/3″

100×21.9×50



60×11×Φ1.2

140

YLC-700

30

320

DN100/4″

100×21.9×50



60×11×Φ1.2

150

YLC-1000

40

360

DN100/4″

100×21.9×50



60×11×Φ1.2

160

YLC-1200

50

400

DN125/5″

100×21.9×50



60×11×Φ1.2

180

YLC-1500

60

420

DN150/6″

170×27.3×57



120×16×Φ1.4

210

YLC-2000

80

560

DN150/6″

170×27.3×57



120×16×Φ1.4

220

YLC-2500

100

700

DN150/6″

170×27.3×57

60×128×30

(W×H×D)

120×16×Φ1.4

275

YLC-3000

125

840

DN150/6″

170×27.3×57



120×16×Φ1.4

300

YLC-4000

150

1120

DN200/8″

173×32.5×65



120×20×Φ1.6

325

YLC-5000

200

1400

DN200/8″

173×37.7×72



120×22×Φ1.6

350

YLC-7000

300

2100

DN250/10″

175×42.6×80



120×24×Φ2.0

400

YLC-10K

400

2520

DN250/10″

176×52.9×95

60×150×40

(W×H×D)

120×22×Φ2.2

475

YLC-15K

600

3080

DN300/12″

176×78×110



120×32×Φ2.4

600

YLC-20K

800

3920

DN350/14″

Designated

Designated

Designated

Designated

YLC-25K

1000

4760

DN350/14″

Designated

Designated

Designated

Designated





FAQ:



01. What is the source of raw water to be treated?

-- is it underground water or well water? or river water ,other source?

02. What is the capacity(m3/hour) you required for this sterilizer?

-- most IMPORTANT requirement.

03. What will the treated water be used for?

--for human drinking or industry purpose?

04. What is the power supply in your country?

   220V/60Hz or other?



Products show:



Explosion-Proof Ultraviolet Water Purification Uv Light Sterilization , Large Capacity 0
