Automatical Industrial Water Treatment Equipment With Mechanical Filter 5000L/H

Name: Automatical Industrial Water Treatment Equipment With Mechanical Filter 5000L/H
Brand: StepChina
SKU: 5000 L/H
Price: 1.00 USD
Availability: InStock
Rating: 4.7 (124 reviews)

Large Image : Automatical Industrial Water Treatment Equipment With Mechanical Filter 5000L/H

Product Details:

Place of Origin:	China
Brand Name:	StepChina
Model Number:	5000 L/H

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Wooden case
Delivery Time:	20-30 days
Payment Terms:	T/T, L/C
Supply Ability:	15 sets/year

Contact Now

Detailed Product Description

Capacity:	5000L/H	Material:	SUS304
Usage:	Purified Water, Drinking Water	Raw Water:	Well Water, Underground Water
Treatment Process:	Mechanical Filter, Reverse Osmosis	Sterilization:	Ozone Sterilization
High Light:	water treatment machine , water treatment system

Automatical Industrial Water Treatment Equipments With Mechanical Filter 5000L/H

Quick Detail

Name

Water treatment system, water treatment equipment, water treatment plant

Brand Name

Step China

Capacity

5000L/H

Material

Stainless steel 304

Raw water

Underground water, well water, borehole water

Usage

Drinking water, purified water, bottled water

Description:

Purpose: purified water
Total water consumption: 8m³/h
Output water: purified water 5m³/h
Configuration: pre-treatment 8m³/h,first-stage RO purified water 5m³/hr and some interrelated assistant equipment.
RO first-stage: output rate 75%.
Operation process: pre-treatment manually, Reverse osmosis automatically.
Water supply: continuously

Automatical Industrial Water Treatment Equipment With Mechanical Filter 5000L/H 0

Applications:

1. A. purified water for bottled water production.
B. drinking water for hotel, office and factory directly supply.

Note:

the configuration of water treatment system is decided by raw water quality. the client should send water analysis report of raw water to us for detailed proposal.

water treatment system, also called water filtration sterilizer system, is the process of purifying the raw water by a series equipment and devices to be drinkable. this system is used to remove the suspended solid, color& smell, bacteria, microbe, metal hydronium and chemical pollution contained in raw water. the water purification process affects the quality of the products, as well as the transportation. the water treatment system adopts the modern, energy-saving and effective membrane separate technology, ozone sterilizing and UV sterilizing to guarantee the production safely and healthily. the water treatment equipment includes silica sand filter, active carbon filter, sodium-ion exchanger, precision filter, reverse osmosis, hollow fiber filter, ozone generator, ozone mixing tank and water tank etc.

Specifications

No.	Product name	Model	Qty.	Capacity
1	Resource water pump	CHL8-40	1piece	8T/H
2	Silica sand filter	SYS-8	1piece	8T/H
3	Active carbon filter	HXT-8	1piece	8T/H
4	Dosing device	JY-1	1piece
5	Precision filter	5μ&1μ	2pieces	8T/H
6	Reverse Osmosis	Ro-1	1piece	5T/H
7	Ozone sterilizer (air type)	15g	1piece	15g
8	Ozone mixing tank	5T	1piece	5T
9	Tank	3T	1piece	3T
10	Pipes&valves	PVC	1 set

Contact us for details

Competitive Advantage:

Advanced membrane technology for water purification, automatic control for water purification, water level sensor, high quality stainless steel 304.

Option

Pretreatment	Sand filter
Back washing function	Manual or automatic
Membrane filtration	Reverse osmosis membrane (DOW)
Pipes	PVC or SUS304
Electric elements	Siemens, Schneider, Mitsubishi, MV, Banner, Turck
